| Tape Backup Technology |
|
LTO5 Holds up to 16 data cartridges (2 magazines) |
| Maximum Storage Capacity |
|
Native: 24TB LTO5 |
| Transfer Rate and Backup Rate |
|
| Native Maximums (LTO5-140) 140MB/s 504GB/hr |
| Drives |
|
| PowerVault 124T LTO-5-140 Drive Cartridge Capacity (Native): 1.5TB |
| Recommended Server Capacity and Environment |
|
High end departmental and enterprise servers Rack dense servers that require external tape backup solutions |
| Server Compatability |
|
Dell and x86 IBM and HP Servers
|
| Reliability |
|
Autoloader MCBF: Greater than 400,000 hours with 100% duty cycle |
| Operations |
|
Cartridge loading: single front loading slot Cartridge inventory time: Less than 1 minute, 15 seconds Manual entry of cartridge to magazine: Less than 1 minute |
| Autoloader Indicators/Controls |
|
5-button with 2-line, 16 character LCD menu display (with backlight) Operational status LEDs |
| Drive Interface |
|
| SAS (LTO-5-140) Dell Supported: PCIe U320 HBA, SAS5/E HBA or 6Gb HBA |
| Cabling Options |
|
No cables PCIe U320 SCSI HBA & VHDCI to 68-pin cable VHDCI to 68-pin cable with no controller card SAS cable for SAS HBA connect |
| Backup Software |
|
| Dell-supported Tape Backup Software: Symantec® Backup ExecTM for Microsoft® Windows® and Novell® NetWare® CommVault® GalaxyTM for Microsoft Windows, Novell NetWare and Linux®
|
| Model/Chassis |
|
2U, Rackmount, 1 tape drive 9cm (3.4") (h) x 43cm (16.77") (w) x 70cm (27.52") (d) Weight with drive: 34 lbs (15.42 kg) without packaging/accessories |
| Power |
|
Power Requirements: 100-240 VAC Inrush Current: 4.0 A (RMS) for 115 VAC, 4.0 A (RMS) for 230 VAC Power Consumption: 60 Hz = 75 W; 50 Hz = 80 W |
| Environmental |
|
Operating Temperature: 10 to 35° C Non-Operating Temperature: -40 to 65° C Operating Humidity: 20% to 80% RH, noncondensing Non-Operating Humidity: 10% to 90% RH, noncondensin |
