| of tape cartridge slots |
12-24 |
 |
| # of tape drives |
1-2 |
|
| # of mail slots |
1 |
|
| Tape drives supported |
LTO6, LTO5 |
|
| Minimum Capacity |
LTO6: 30-60TB
LTO5: 18-36TB |
|
| Maximum Capacity |
LTO6: 75-150TB
LTO5: 36-72TB |
|
| Minimum data transfer rate |
LTO6: 576GB/hr
LTO5: 504GB/hr |
|
| Maximum data transfer rate |
LTO6: 2.9TB/hr
LTO5: 2.0TB/hr |
|
| Interfaces |
6Gb SAS, 8Gb FC |
|
| Connectors |
Mini-SAS, LC optical FC |
|
| Form Factor |
2U |
|
| Dimensions (inches) |
3.44"(h) x 17.6"(w) x 29.13"(d) |
|
| Dimensions (mm) |
87.4mm x 447.0mm x 739.9mm |
|
| Weight (pounds - unpackaged) |
33 / 14.9kg |
|
| Avg. cartridge swap time |
45 seconds |
|
| Inventory time |
1:20 minutes |
|
| Power Requirements |
168 watts (max) |
|
| Input Requirements |
100 to 240 VAC, 50 to 60 Hz |
|
| Humidity (non-condensing; operating) |
10% to 80% |
|
| Temperature range (operating) |
50° to 113° F (10° to 45° C) |
|
| Reliability |
>2,000,000 MCBF (robotic load/unload cycles) |
|
| Standard Warranty |
NEO S-Series libraries include one-year OverlandCare Bronze Support Coverage, which includes 5x9 telephone support and advanced parts replacement. |
