Power Supply
|
(100-240VAC ±5%, 50/60 Hz.) Field Selectable.
Factory configured for 120 VAC unless specified on P.O.
|
Power Consumption
|
Under standby: 0.5A
While charging: 8.0A < 1 second
At the time of Erase: 0.5A
|
Degausser System
|
Capacitive Discharge
|
Duty Cycle
|
Continuous
|
Erasure Time
|
45 second repetitive cycle
|
Magnetic Field
|
2.0 Tesla (20,000 gauss)
|
Certifications
|
NSA/CSS
|
Erasing Area Size
|
1.0 in. (H) x 4.5 in. (W) x 6.75 in. (D)
|
Portability Features
|
Two 6" wide retractable machined alloy handles on each side.
|
Media |
Hard drives up to one inch high including full height, standard and laptop drives, tape cartridges including DLT, LTO, 3590 Series, 8mm and more. |
Temperature |
10°F - 112°F (-12°C - 45°C) |
Humidity |
10%H - 40%H (non-condensing) |
Weight:
|
TS-1: 144 lbs. (66 kg) Shipping: 160 lbs. (73 kg)
|
Size: TS-1
|
TS-1: 21.5 x 17.5 x 19 in. Shipping: 34 x 26 x 33 in.
(546 x 444 x 482 mm) (864 x 660 x 838 mm)
|
Warranty |
One Year Factory Warranty standard.
Extended Warranty available.
|
