| Form Factor |
1U Rackmount or Desktop Versions |
| Capacity |
Media dependent (online): 8TB using 4 x 2TB pieces of media. Unlimited offline capacity |
| Data Transfer Rate |
Up to 200 MB/s, concurrent read/write operations |
| Logical Media Move Time |
<1 second |
| Network Connectivity |
2 x 1 Gigabit Ethernet, bonded, active backup/failover or adaptive load balancing |
| Configuration Options |
1-4 individual RDX QuikStor removable disk targets (addressable via 1 to 4 hosts)
1-4 individual RDX QuikStor fixed disk targets (for Windows Backup)
1 Logical Volume across all RDX drives |
| Remote Management |
Integrated browser-based management console with multi language support for English, French, German, Spanish, Italian, Norwegian, Russian, Chinese & Japanese. |
| USB 2.0 Ports |
1 Front, 2 Rear |
| Removable Media Drive |
4 x RDX drives |
| RDX Media Compatibility |
Backward & Forward compatible will all RDX media and RDX+ media generations:
500GB, 1TB or 2TB (HDD); 128GB, 256GB or 512GB (SSD) |
Environmental Specifications
|
| Power Input |
100 - 240 Vac, 50 - 60Hz |
| Power Consumption |
<90 Watts, typical |
| Environmental Compliance |
EU RoHS, China RoHS, REACH, WEEE |
| Safety & Regulatory |
FCC Class AB, UL, CE, TÜV-GS, CB C-Tick, VCCI, AS/NZS CISPR22, NMB-003, KCC |
Product Specifications
|
| Unit Dimensions Rackmount (DxWxH) |
478mm x 440mm x 43mm / 18.82in. x 17.32in. x 1.69in. |
| Unit Dimensions Desktop (DxWxH) |
481mm x 464.5mm x 68mm / 18.94in. x 18.29in. x 2.68in. |
| Packaged Dimensions (DxWxH) |
655mm x 605mm x 220mm / 25.8in. x 23.8in. x 8.7in. |
| Net Weight Rackmount |
5.98kg / 13.18lb |
| Net Weight Desktop |
9.77kg / 21.54lb |
| Gross Weight Rackmount (Packaged) |
11.3kg / 25lb |
| Gross Weight Desktop (Packaged) |
13.6kg / 30lb |
| Operating Temperature |
10° to 40° C (50° to 104° F) |
| Non-Operating Temperature |
-20° to 60° C (-4° to 140° F) |
| Operating Humidity (Non-condensing) |
20% to 80% |
Other Features
|
| Included in the Box |
Ethernet cables (2), US and Euro power cords, USB Flash Drive, Rackmount Kit, Quick Start Guide
(RDX media not included) |
| Warranty |
3-Year Bronze Level Support (Advanced Replacement Service, where available)
|
